Complete hardware set includes all necessary hardware to make 1 single door slide, door not included. Track can be cut down to fit smaller door/opening widths. Pocket door hardware for interior applications, residential or light commercial. Maximum door weight: 80 lbs. Maximum door thickness: 3/4". Similar to 100PD except designed for lighter weight doors. A versatile single track system designed and packed primarily for "on-the-job" construction of pocket doors, but also usable in combination with itself or other Johnson series tracks for special installations of sliding doors. Aluminum track with convex rails, jump proof three wheel hangers. Heavy gauge steel components are zinc plated for a quality appearance. Components are available in bulk for fabricators, as are fixtures for assembly of pocket door frames. Features: Heavy walled aluminum track is precision extruded for smooth operation. Keyhole mounting slots allow easy removal without tearing out walls. Box design prevents rollers from jumping track. Convex rail design provides single point hanger wheel contact for low roll resistance, and dust traps on both sides of rails allow hangers to operate freely when dust builds up. Tricycle hanger design gives even weight distribution on track rails and will not bind. Machine turned and balanced wheels offer low roll resistance, feather touch operation. Hangers are height adjustable for precision door alignment. Detachable hanger plate allows easy door installation or removal. Adjustable jamb mount door guide effectively holds door in place without binding and insures smooth door operation. SETS INCLUDE ALL NECESSARY HARDWARE LESS DOORS, TRACK CAN BE CUT DOW TO FIT SMALLER SIZE OPENINGS.

For installation instructions click here.

For installation instructions for bypass (double) door installation, click here.
